Model |
Description |
3320-051 |
Rigid - Non-Metered |
3/4" NPT(F) (F) Inlet |
3320-052 |
Flex - Non-Metered |
3/4" NPT(F) (F) Inlet |
3320-053 |
Rigid - Non-Metered |
1" NPT(F) (F) Inlet |
3320-054 |
Flex - Non-Metered |
1" NPT(F) (F) Inlet |
Technical Data
|
Units of measure |
Batch: Liters, quarts, pints, gallons |
Accuracy |
+/-0.5% of reading |
Flow Range |
0.26-24 gal/min (1-90 l/min) |
Maximum pressure |
1,450 psi (100 bar) |
Swivel inlet |
3/4" or 1" NPT(F) |
Operating temperature |
14 to 140 ºF (-10 to 60 ºC) |
Weight |
4.5 lb (2.05 kg) |
Compatible Fluids |
Oil, transmission fluid, hydraulic fluid, and anti-freeze solutions |
Wetted Materials |
Aluminum, Buna-NTM, zinc plated steel and brass |
- HighFlo Control Handle is designed for service where higher volume deliveries are required.
- High volume rigid or flexible outlets with non-drip tip.
- 3/4" or 1" NPT inlet connection thread.
- Ideal for bulk fill, transfer and high flow dispense.
- Heavy duty rugged design.
